Product Details:
Payment & Shipping Terms:
|
PPK: | 600 Watts | PD: | 5 Watts |
---|---|---|---|
IFSM: | 100 Amps | VF: | 3.5 / 5.0 Volts |
RθJL: | 10 ℃/W | ||
High Light: | electronic integrated circuit,linear integrated circuits |
Features
UL Recognized File # E-326243
Qualified as per AEC-Q101
Plastic package has Underwriters Laboratory Flammability Classification 94V-0
600 watts surge capability at 10 / 1000 us waveform
Excellent clamping capability
Low Dynamic impedance
Fast response time: Typically less than 1.0ps from 0 volt to VBR for unidirectional and 5.0ns for bidirectional
Typical IR less than 1uA above 10V
High temperature soldering guaranteed: 260℃ / 10 seconds / .375",(9.5mm) lead length / 5lbs., (2.3kg) tension
Green compound with suffix "G" on packing code & prefix "G" on datecode
Mechanical Data
Case: Molded plastic
Lead: Pure tin plated lead free, solderable per MIL-STD-202, Method 208
Polarity: Color band denotes cathode except bipolar
Weight: 0.42 gram
