TOP244YN TOPSwitch-GX Family Extended Power, Design Flexible, EcoSmart, Integrated Off-line Switcher

: Large Image : TOP244YN TOPSwitch-GX Family Extended Power, Design Flexible, EcoSmart, Integrated Off-line Switcher

Product Details:

Place of Origin:	brand new
Brand Name:	POWERINT
Certification:	Original Factory Pack
Model Number:	TOP244YN

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	5200PCS

Contact Now

Detailed Product Description

DRAIN Voltage:	-0.3 V To 700 V	DRAIN Peak Current::	..2.16 A
CONTROL Voltage:	-0.3 V To 9 V	CONTROL Current:	. 100 MA
LINE SENSE Pin Voltage:	. -0.3 V To 9 V
High Light:	power mosfet ic , multi emitter transistor

Lower System Cost, High Design Flexibility

TOP244YN TOPSwitch-GX Family Extended Power, Design Flexible, EcoSmart, Integrated Off-line Switcher Product Highlights

Lower System Cost, High Design Flexibility

• Extended power range for higher power applications

• No heatsink required up to 34 W using P package

• Features eliminate or reduce cost of external components

• Fully integrated soft-start for minimum stress/overshoot

• Externally programmable accurate current limit

• Wider duty cycle for more power, smaller input capacitor

• Separate line sense and current limit pins on Y/R/F packages

• Line under-voltage (UV) detection: no turn off glitches

• Line overvoltage (OV) shutdown extends line surge limit

• Line feed-forward with maximum duty cycle (DCMAX) reduction rejects line ripple and limits DCMAX at high line

• Frequency jittering reduces EMI and EMI filtering costs

• Regulates to zero load without dummy loading

• 132 kHz frequency reduces transformer/power supply size

• Half frequency option in Y/R/F packages for video applications TOP244YN TOPSwitch-GX Family Extended Power, Design Flexible, EcoSmart, Integrated Off-line Switcher

• Hysteretic thermal shutdown for automatic fault recovery

• Large thermal hysteresis prevents PC board overheating

EcoSmart - Energy Efficient

• Extremely low consumption in remote off mode (80 mW at 110 VAC, 160 mW at 230 VAC)

• Frequency lowered with load for high standby efficiency

• Allows shutdown/wake-up via LAN/input port

TOP244YN TOPSwitch-GX Family Extended Power, Design Flexible, EcoSmart, Integrated Off-line Switcher
