VCBO: | 80 –60 V | VCEO: | 60 –60 V |
---|---|---|---|
VEBO: | 6 –6 V | IC: | 4 –4 A |
PT: | 4 (Ta=25°C) W | ||
High Light: | multi emitter transistor,silicon power transistors |
Absolute maximum ratings
Symbol | Specification | Unit | |
NPN | PNP | ||
VCBO | 80 | –60 | V |
VCEO | 60 | –60 | V |
VEBO | 6 | –6 | V |
IC | 4 | –4 | A |
ICP |
8 (PW≤10ms, Du≤50%) |
–8 (PW≤10ms, Du≤50%) |
A |
PT | 4 (Ta=25°C) | W | |
20 (Tc=25°C) | |||
Tj | 150 | °C | |
Tstg | –40 to +150 | °C |
■Equivalent circuit diagram
Characteristic curves
