Detailed Product Description
Output Current: 1.5 A Output Voltages: 5; 6; 8; 8.5; 9; 12; 15; 18; 24 V
Protection: Thermal Overload Protection TJ: 25°C
Operating Junction Temperature Range: 0 To 150 °C


L78xxC

Positive voltage regulators


Positive voltage regulators Thermal overload protection Short circuit protection L7805CV

Features

■ Output current to 1.5 A

■ Output voltages of 5; 6; 8; 8.5; 9; 12; 15; 18; 24 V

■ Thermal overload protection

■ Short circuit protection

■ Output transition SOA protection



Description

The L78xx series of three-terminal positive regulators is available in TO-220, TO-220FP, TO-3, D2PAK and DPAK packages and several fixed output voltages, making it useful in a wide range of applications. These regulators can provide local on-card regulation, eliminating the distribution problems associated with single point regulation. Each type employs internal current limiting, thermal shut-down and safe area protection, making it essentially indestructible. If adequate heat sinking is provided, they can deliver over 1 A output current. Although designed primarily as fixed voltage regulators, these devices can be used with

external components to obtain adjustable voltage and currents.



Figure 1. Block diagram

Positive voltage regulators Thermal overload protection Short circuit protection L7805CV



Figure 2. Pin connections (top view)

Positive voltage regulators Thermal overload protection Short circuit protection L7805CV

Absolute maximum ratings

Symbol  Parameter  Value Unit
VI DC input voltage for VO= 5 to 18 V 35 V
DC input voltage  for VO= 20, 24 V 40 V
I Output current  Internally limited
P Power dissipation  Internally limited
TSTG   Storage temperature range -65 to 150  °C
TOP Operating junction temperature range For L7800 -55 to 150 °C
Operating junction temperature range for L7800C 0 to 150 °C
