Short Circuit Power Mosfet Transistors Autoprotected VND3NV0413TR
Features
| Type | RDS(on) | Ilim | Vclamp |
|
VNN3NV04 VNS3NV04 VND3NV04 VND3NV04-1 |
120 mΩ | 3.5 A | 40 V |
■ Linear current limitation
■ Thermal shutdown
■ Short circuit protection
■ Integrated clamp
■ Low current drawn from input pin
■ Diagnostic feedback through input pin
■ ESD protection
■ Direct access to the gate of the Power MOSFET (analog driving)
■ Compatible with standard Power MOSFET in compliance with the 2002/95/EC European Directive
Description
The VNN3NV04, VNS3NV04, VND3NV04 VND3NV04-1, are monolithic devices designed in STMicroelectronics VIPower M0-3 Technology, intended for replacement of standard Power MOSFETs from DC up to 50 kHz applications. Built in thermal shutdown, linear current limitation and overvoltage clamp protect the chip in harsh environments.
Fault feedback can be detected by monitoring the voltage at the input pin.
Device summary
| Package | Order codes | |||
| Tube | Tube (lead-free) | Tape and reel | Tape and reel (lead-free) | |
| SOT-223 | VNN3NV04 | - | VNN3NV0413TR | - |
| SO-8 | VNS3NV04 | - | VNS3NV0413TR | - |
| TO-252 | VND3NV04 | VND3NV04-E | VND3NV0413TR | VND3NV04TR-E |
Block diagram and pin description
