Product Details:
Payment & Shipping Terms:
|
| Temperature Range: | –40°C To +150°C | Payment Term: | T/T, Paypal, Western Union |
|---|---|---|---|
| Voltage: | –0.3 To 4.2 V | Current: | 9mA |
| Package: | HTSSOP-44 | Factory Package: | 2000pcs/reel |
| High Light: | ic programmer circuit,programmable audio chip |
||
Features
• PurePath™ HD Integrated Feedback Provides:
– 0.03% THD at 1 W into 4 Ω
– >65 dB PSRR (No Input Signal)
– >105 dB (A weighted) SNR
• Pre-Clipping Output for Control of a Class-G Power Supply
• Reduced Heat Sink Size due to use of 60mΩ
Output MOSFET with >90% Efficiency at Full
Output Power
• Output Power at 10%THD+N
– 150 W / 4 Ω BTL Stereo Configuration
– 300 W / 2 Ω in PBTL Mono Configuration
• Output Power at 1%THD+N
– 125 W / 4 Ω BTL Stereo Configuration
– 65 W / 8 Ω BTL Stereo Configuration
APPLICATIONS
• Blu-ray™/DVD Receivers
• High Power Sound Bars
• Powered Subwoofer and Active Speakers
• Mini Combo Systems
| ABSOLUTE MAXIMUM RATINGS(1) |
|
VDD to GND, GVDD_X(2) to GND –0.3 to 13.2 V
PVDD_X(2) to GND(3) , OUT_X to GND(3) , BST_X to GVDD_X(2)(3) –0.3 to 50 V
BST_X to GND(3)(4) –0.3 to 62.5 V
DVDD to GND –0.3 to 4.2 V
AVDD to GND –0.3 to 8.5 V
OC_ADJ, M1, M2, M3, C_START, INPUT_X to GND –0.3 to 4.2 V
RESET, FAULT, OTW, CLIP, to GND –0.3 to 4.2 V
Maximum continuous sink current (FAULT, OTW, CLIP) 9 mA
Maximum operating junction temperature range, TJ 0 to 150 °C
Storage temperature, Tstg –40 to 150 °C Lead temperature 260 °C
Human body model(4) (all pins) ±2 kV
Electrostatic discharge Charged device model(4) (all pins) ±500 V
|
