BM06B-SRSS-TB Disconnectable Insulation displacement connectors

China BM06B-SRSS-TB Disconnectable Insulation displacement connectors supplier

Large Image :  BM06B-SRSS-TB Disconnectable Insulation displacement connectors

Product Details:

Place of Origin: original factory
Brand Name: Anterwell
Certification: new & original
Model Number: BM06B-SRSS-TB

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: Negotiate
Packaging Details: Please contact me for details
Delivery Time: 1 day
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 7200pcs
Contact Now
Detailed Product Description
Current Rating: 0.7A DC Voltage Rating: 50V DC
Temperature Range: -25˚C To +85˚C Insulation Resistance: 100M Ω Min
Withstanding Voltage: 500V AC/minute Contact Resistance: Initial Value/20m Ω Max
High Light:

chip in electronics

,

integrated components



SR CONNECTOR



Disconnectable Insulation displacement connectors



Features

• Ultra-compact insulation displacement connector

1.0mm (.039") pitch and only 3.0mm (.118") high (side entry type). This connector is only about 61% as large as the smallest conventional (JST) IDC designs.



• Header designed for vacuum pick and place robotics

Although this shrouded header has locking features for its mating receptacle, there are no holes in the header shroud that would adversely effect vacuum grippig equipment. Since there is enough flat surface for secure vacuum gripping, this miniature surface mount connector is versatile for designers and economic for manufacturing.



• Twin U-slot insulation displacement section

The insulation displacement section connected to each wire consists of two tin-plated slots (twin U-slots), which ensures reliable connection.



• 3-point grip construction

The 3-point insulation grip feature and the strain relief ensure a firm grip on terminated wires and protection of the insulation displacement connection from possible damage.



Specifications

• Current rating: 0.7A DC

• Voltage rating: 50V DC

• Temperature range: -25˚C to +85˚C

  (including temperature rise in applying electrical current)



• Contact resistance: Initial value/20m Ω max.

                                 After environmental testing/40m Ω max.

• Insulation resistance: 100M Ω min.

• Withstanding voltage: 500V AC/minute

• Applicable wire: AWG #30 Conductor/7 strands, tin-coated annealed copper

                                            Insulation O.D./0.56mm (.022") * Contact JST for details.



BM06B-SRSS-TB Disconnectable Insulation displacement connectors



BM06B-SRSS-TB Disconnectable Insulation displacement connectors
