FSBB30CH60F Mosfet Power Module thyristor diode Smart Power Module

China FSBB30CH60F Mosfet Power Module thyristor diode Smart Power Module supplier

Large Image :  FSBB30CH60F Mosfet Power Module thyristor diode Smart Power Module

Product Details:

Place of Origin: original factory
Brand Name: Anterwell
Certification: new & original
Model Number: FSBB30CH60F

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: Negotiate
Packaging Details: Please contact me for details
Delivery Time: 1 day
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 6100pcs
Contact Now
Detailed Product Description
Supply Voltage: 450 V Supply Voltage (Surge): 500 V
Collector-emitter Voltage: 600 V Each IGBT Collector Current: 30 A
Collector Dissipation: 103 W Operating Junction Temperature: -20 ~ 125 °C
High Light:

low voltage power mosfet

,

hybrid inverter circuit



FSBB30CH60F Mosfet Power Module thyristor diode Smart Power Module



Features

• UL Certified No.E209204(SPM27-EA package)

• Very low thermal resistance due to using DBC

• 600V-30A 3-phase IGBT inverter bridge including control ICs for gate driving and protection

• Divided negative dc-link terminals for inverter current sensing applications

• Single-grounded power supply due to built-in HVIC

• Isolation rating of 2500Vrms/min.



Applications

• AC 100V ~ 253V three-phase inverter drive for small power ac motor drives

• Home appliances applications like air conditioner and washing machine.



General Description

It is an advanced smart power module (SPMTM) that Fairchild has newly developed and designed to provide very compact and high performance ac motor drives mainly targeting lowpower inverter-driven application like air conditioner and washing machine. It combines optimized circuit protection and drive matched to low-loss IGBTs. System reliability is further enhanced by the integrated under-voltage lock-out and shortcircuit protection. The high speed built-in HVIC provides optocoupler-less single-supply IGBT gate driving capability that further reduce the overall size of the inverter system design. Each phase current of inverter can be monitored separately due to the divided negative dc terminals.



Integrated Power Functions

• 600V-30A IGBT inverter for three-phase DC/AC power conversion (Please refer to Figure 3)



Integrated Drive, Protection and System Control Functions

• For inverter high-side IGBTs:

Gate drive circuit, High voltage isolated high-speed level shifting

Control circuit under-voltage (UV) protection



• For inverter low-side IGBTs:

Gate drive circuit, Short circuit protection (SC)

Control supply circuit under-voltage (UV) protection



• Fault signaling: Corresponding to a UV fault (Low-side supply)

• Input interface: 3.3/5V CMOS/LSTTL compatible, Schmitt trigger input



Absolute Maximum Ratings (TJ = 25°C, Unless Otherwise Specified)

Inverter Part

Symbol Parameter Conditions Rating Units
VPN Supply Voltage Applied between P- NU, NV, NW 450 V
VPN(Surge) Supply Voltage (Surge) Applied between P- NU, NV, NW 500 V
VCES Collector-emitter Voltage   600 V
± IC Each IGBT Collector Current TC = 25°C 30 A
± ICP Each IGBT Collector Current (Peak) TC = 25°C, Under 1ms Pulse Width 60 A
PC Collector Dissipation TC = 25°C per One Chip 103 W
TJ Operating Junction Temperature (Note 1) -20 ~ 125 °C

Note:

1. The maximum junction temperature rating of the power chips integrated within the SPM is 150°C(@TC ≤ 100°C). However, to insure safe operation of the SPM, the average junction temperature should be limited to TJ(ave) ≤ 125°C (@TC ≤ 100°C)



FSBB30CH60F Mosfet Power Module thyristor diode Smart Power Module



Pin Configuration

FSBB30CH60F Mosfet Power Module thyristor diode Smart Power Module



Internal Equivalent Circuit and Input/Output Pins

FSBB30CH60F Mosfet Power Module thyristor diode Smart Power Module
