SS443A digital pressure sensor ic , Position Sensors electronic components ic

: Large Image : SS443A digital pressure sensor ic , Position Sensors electronic components ic

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	SS443A

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	9300pcs

Contact Now

Detailed Product Description

Supply Voltage:	3.8 To 30 V	Supply Current (max.):	10 MA
Output Voltage (max.):	40 V	Output Current, Max.:	20 MA
Output Leakage Current, Max.:	10 µA	Operating Temperature:	–40 To +150°C
High Light:	electronic pressure sensors , hall effect sensor ic

Stock Offer (Hot Sell)

Part no.

Quantity

Brand

D/C

Package

B57460	889	PHI	14+	PHI
BTS640S2G	889		14+	TO-263
IRG4PH30K	897	IR	14+	TO-247
PC956L	899	SHARP	16+	SOP8
VB025MSP	900	ST	16+	SOP10
XC2C32A-6VQG44C	900	XILINX	13+	QFP44
AD9958BCPZ	911	AD	15+	QFP
LM22672MR-ADJ	911	NS	16+	SOP8
SN65LVDS104PWR	911	TI	16+	TSSOP-16
W83627DHG-A	911	WINBOND	14+	QFP
LM2671M-ADJ	972	NS	14+	SOP8
BD649	975	ST	14+	TO-220
DS1220Y-100	980	DALLAS	16+	DIP
BUT11APX	987	NXP	16+	TO-220
CD4097BE	987	TI	13+	DIP
GAL20V8B-15LP	988	LATTICE	15+	DIP
PMM8714PT	990	SANYO	16+	DIP24
BTM7755G	997		16+	SOP
2SK683	998	HIT	14+	TO-3P
D82C55AC-2	998	NEC	14+	DIP
VN66AFD	998	VISHAY	14+	TO220
LM1881N	999	NS	16+	DIP8
24LC64-I/P	1000	MICROCHIP	16+	DIP-8
2SA1987	1000	TOSHIBA	13+	TO-3P
6B595	1000	TI	15+	DIP
ADM202JN	1000	AD	16+	DIP
ADXL103CE	1000	AD	16+	CLCC-8
AM27C256-55DC	1000	AMD	14+	DIP
AS176-59	1000	SKYWOR	14+	MSOP-8
AT89C52-24JI	1000	ATMEL	14+	PLCC

Solid State Sensors SS400 Series

Digital Position Sensors

FEATURES

3.8-30 VDC supply voltage
Digital current sinking output
3 pin in-line PCB terminals
Quad-Hall design virtually eliminates mechanical stress effects
Temperature compensated magnetics
Operate/release points can be customized

Bipolar, unipolar, latching magnetics
High output current capability –50 mA absolute maximum
Operate/release points symmetrical around zero gauss (bipolar/latch)
Operating temperature range of –40 to +150°C (–40 to +302°F)
Package material: Plaskon 3300H
Surface mount version available: SS400-S (with cut and formed leads)

SS400 Series position sensors have a thermally balanced integrated circuit over full temperature range. The negative compensation slope is optimized to match the negative temperature coefficient of lower cost magnets. Bipolar, latching and unipolar magnetics are available.

Band gap regulation provides extremely stable operation over 3.8 to 30 VDC supply voltage range. SS400 sensors are capable of continuous 20 mA sinking output, and may be cycled as high as 50 mA maximum.
