SC9153 Integrated Circuit Chip CMOS IC ELECTRONIC VOLUME CONTROLLER

China SC9153 Integrated Circuit Chip CMOS IC ELECTRONIC VOLUME CONTROLLER supplier

Large Image :  SC9153 Integrated Circuit Chip CMOS IC ELECTRONIC VOLUME CONTROLLER

Product Details:

Place of Origin: original factory
Brand Name: Anterwell
Certification: new & original
Model Number: SC9153

Payment & Shipping Terms:

Minimum Order Quantity: 20pcs
Price: Negotiate
Packaging Details: Please contact me for details
Delivery Time: 1 day
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 7000pcs
Contact Now
Detailed Product Description
Supply Voltage(Pin 16): 13.0 V Power Dissipation: 150 MW
Operating Temperature: -30 ~ +75 °C Storage Temperature: -55 ~ +125 °C
High Light:

integrated circuit ic

,

integrated circuit components



SC9153A

ELECTRONIC VOLUME CONTROLLER





DESCRIPTION SC9153 Integrated Circuit Chip CMOS IC ELECTRONIC VOLUME CONTROLLER

The SC9153A is CMOS IC which has been designed for electronization volume control of audio equipment,etc.



FEATURES

*Wide operating voltage range(VDD=6V ~ 12V)

*Low current comsumption .

*Attenuation can be controlled from 0dB to –66dB by 2dB/step

*Both of dual power suppliers of (+) and (-) and a single power supply can be used.

*Be capable of controlling attenuation by means of the built-in oscillator and the up/down terminals.













BLOCK DIAGRAM

SC9153 Integrated Circuit Chip CMOS IC ELECTRONIC VOLUME CONTROLLER



PIN CONFIGURATION

SC9153 Integrated Circuit Chip CMOS IC ELECTRONIC VOLUME CONTROLLER



ABSOLUTE MAXIMUM RATINGS

Characteristic Symbol Value Unit
Supply Voltage(Pin 16) VDD 13.0 V
Input/Output Voltage VIN Vss-0.3V ~ VDD+0.3V V
Power Dissipation PD 150 mW
Operating Temperature Topr -30 ~ +75 °C
Storage Temperature Tstg -55 ~ +125 °C
