SMP1322-017LF-TR3 Low Resistance Plastic Packaged PIN Diodes

China SMP1322-017LF-TR3 Low Resistance Plastic Packaged PIN Diodes supplier

Large Image :  SMP1322-017LF-TR3 Low Resistance Plastic Packaged PIN Diodes

Product Details:

Place of Origin: original factory
Brand Name: anterwell
Certification: new & original
Model Number: SMP1322-017LF-TR3

Payment & Shipping Terms:

Minimum Order Quantity: 20pcs
Price: Negotiate
Packaging Details: Please contact me for details
Payment Terms: Western Union, T/T, MoneyGram
Supply Ability: 5000pcs
Contact Now
Detailed Product Description
Voltage - Peak Reverse (maximum): 50V Different Vr, F Time Capacitance: 1.15pF @ 30V,1MHz
Different If And F Resistance: 500mA @ 10mA,100MHz Power Dissipation (maximum): 250mW
High Light:

diode rectifier circuit

,

bridge rectifier circuit

SMP1322-017LF-TR3 Low Resistance Plastic Packaged PIN Diodes



Features



Designed for High Performance Wireless Switch Applications

Specified 1.5 Ω @ 1 mA

Multiple Package Configurations





Description



The SMP1322 series of plastic packaged, surface mountable PIN diodes are designed for high volume switch applications from 10 MHz to beyond 2 GHz.The ultra low resistance of these diodes (1.5 Ω maximum at 1 mA and 0.5 Ω typical at 10 mA) make the SMP1322 series particularly suited to low loss PIN diode switches in battery operated circuits. Available in a selection of plastic packages and in a variety of configurations including an ultra low inductance (0.2 nH) SOT-143 (SMP1322-017), the small footprint SC-79 and the miniature SC-70. In addition, the SMP1322-016 consists of 2 diodes in a SOT-143 package configured to enable insertion in a quarter-wave T/R switch with no crossover connections.





Absolute Maximum Ratings



Characteristic Value
Reverse Voltage (VR) 50V

Power Dissipation @ 25°C Lead

Temperature (PD)

250 mW
Storage Temperature (TST) -65°C to +150°C
Operating Temperature (TOP) -65°C to +150°C
ESD Human Body Model Class 1B







Electrical Specifications at 25°C



Parameter Condition Typ. Max. Unit
Reverse Current (IR) VR = 50 V   10 µA
Capacitance (CT) F = 1 MHz, V = 30 V   1.0 pF
Resistance (RS) F = 100 MHz, I = 1 mA   1.5
Resistance (RS) F = 100 MHz, I = 10 mA 0.5
Forward Voltage (VF) IF = 10 mA 0.85   V
Carrier Lifetime (TI) IF = 10 mA 0.4   µS
I Region Width   8   µm







SMP1322-007



In the -007 configuration of the SOT-23 package, the package inductance is effectively reduced to 0.4 nH, in comparison to the 1.5 nH value of the standard configuration. This lower inductance will be particularly beneficial when the diodes are used as shunt connected switches at frequencies higher than 500 MHz, where inductance is the primary limitation on maximum switch isolation. To achieve the effective 0.4 nH, the SOT-23 package must be inserted in the microstrip circuit board with a gap in the trace, as shown in the figure. Because of the polarity of the diode junction, this low inductance feature is only realizable with the cathod





SMP1322-017 SOT-143

Low Inductance PIN Diode The SMP1322-017 utilizes the SMP1322 PIN diode chip in a customized SOT-143 plastic package designed for high isolation performance in a shunt connected switch. Its effective inductance, based on the 3 GHz isolation, is less than 0.2 nH.This diode is designed to work effectively as a shunt element in SPDT switches, covering the wireless frequencies from 900 MHz to beyond 2 GHz. Excellent performance is achievable when used in a quarter-wave T/R switch with the SMP1322-001 (SOT-23) or SMP1322-011 (SOD-323) PIN diode as the series connected diode.
