IXFX27N80Q Power Mosfet Transistor HiPerFET Power MOSFETs Q-CLASS

China IXFX27N80Q Power Mosfet Transistor HiPerFET Power MOSFETs Q-CLASS supplier

Large Image :  IXFX27N80Q Power Mosfet Transistor HiPerFET Power MOSFETs Q-CLASS

Product Details:

Place of Origin: original factory
Brand Name: Anterwell
Certification: new & original
Model Number: IXFX27N80Q

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: Negotiate
Packaging Details: Please contact me for details
Delivery Time: 1 day
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 6000pcs
Contact Now
Detailed Product Description
VDSS: 800 V VDGR: 800 V
VGS: 20 V VGSM: 30 V
PD: 500 W TJ: -55 ... +150 ℃
High Light:

power mosfet ic

,

multi emitter transistor



HiPerFETTM Power MOSFETs Q-CLASS

Single MOSFET Die



IXFK 27N80Q

IXFR 27N80Q

IXFX 27N80Q



VDSS = 800 V

ID25 = 27 A

RDS(on) = 300 m

trr ≤ 250 ns



N-Channel Enhancement Mode Avalanche Rated, Low Qg, High dV/dt, Low trr



IXFX27N80Q Power Mosfet Transistor HiPerFET Power MOSFETs Q-CLASS                     IXFX27N80Q Power Mosfet Transistor HiPerFET Power MOSFETs Q-CLASS







































Features

• IXYS advanced low Qg process

• Low gate charge and capacitances

  - easier to drive

  - faster switching

• International standard packages

• Low RDS (on)

• Rated for unclamped Inductive load switching (UIS) rated

• Molding epoxies meet UL 94 V-0 flammability classification



Applications

• DC-DC converters

• Battery chargers

• Switched-mode and resonant-mode power supplies

• DC choppers

• AC motor control

• Temperature and lighting controls



Advantages

• PLUS 247TM package for clip or spring mounting

• Space savings

• High power density



Maximum Ratings

Symbol Test Conditions Max Unit
VDSS TJ = 25℃ to 150℃ 800 V
VDGR TJ = 25℃ to 150℃; RGS = 1 M 800 V
VGS Continuous ±20 V
VGSM Transient ±30 V
ID25 TC = 25℃ 27 A
IDM TC = 25℃, pulse width limited by TJM 108 A
IAR TC = 25℃ 27 A
EAR TC = 25℃ 60 mJ
EAS TC = 25℃ 2.5 J
dv/dt

IS ≤ IDM, di/dt ≤ 100 A/μs, VDD ≤ VDSS

TJ ≤ 150℃, RG = 2 Ω

5 V/ns
PD TC = 25℃ 500 W
TJ   -55 ... +150
TJM   150
Tstg   -55 ... +150
TL 1.6 mm (0.063 in.) from case for 10 s 300
Md Mounting torque TO-264 0.4/6 Nm/lb.in.
Weight

PLUS 247/ISOPLUS 247

TO-264

6

10

g

g
