Product Details:
Payment & Shipping Terms:
|
| Supply Voltage: | 8 V | Control Voltage: | -0.2 V, +8 V |
|---|---|---|---|
| Operating Temperature: | -40 °C To +85 °C | Storage Temperature: | -65 °C To +150 °C |
| High Light: | integrated circuit ic,integrated circuit components |
||
AS214-92, AS214-92LF: PHEMT GaAs IC SPDT Switch 0.1–3 GHz
Applications
● T/R switch in WLANs, BluetoothTM and medium-power telecommunication applications
Features
● Low insertion loss (0.4 dB @ 2.4 GHz)
● Isolation 26 dB @ 2.4 GHz
● Low DC power consumption
● PHEMT process
● Operates at 1.8 V control voltage
● Available lead (Pb)-free and RoHS-compliant MSL-1 @ 260 °C per JEDEC J-STD-020
Description
The AS214-92 is a medium-power IC FET SPDT switch in a lowcost miniature SC-70 6-lead plastic package. The AS214-92 features low insertion loss and positive voltage operation with very low DC power consumption. This general purpose switch can be used in a variety of telecommunications applications.
Pin Out
DC blocking capacitors (CBL) must be supplied externally for positive voltage operation.
CBL = 100 pF for operation >500 MHz.
Absolute Maximum Ratings
| Characteristic | Value |
|---|---|
| RF input power |
2 W max. for f > 500 MHz 500 mW for f < 500 MHz VCTL = 0/8 V |
| Supply voltage | 8 V |
| Control voltage | -0.2 V, +8 V |
| Operating temperature | -40 °C to +85 °C |
| Storage temperature | -65 °C to +150 °C |
Performance is guaranteed only under the conditions listed in the specifications table and is not guaranteed under the full range(s) described by the Absolute Maximum specifications. Exceeding any of the absolute maximum/minimum specifications may result in permanent damage to the device and will void the warranty.
