Product Details:
Payment & Shipping Terms:
|
| Maximum Recurrent Peak Reverse Voltage: | 40 V | Maximum RMS Voltage: | 28 V |
|---|---|---|---|
| Maximum DC Blocking Voltage: | 40 V | Maximum Average Forw Ord Rectified Current At TL: | 3.0 A |
| Operating Junction Temperature: | -65 To +150℃ | Storage Temperature: | -65 To +150℃ |
| High Light: | diode rectifier circuit,signal schottky diode |
||
B320B-B360B
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS
REVERSE VOLTAGE: 20 --- 60 V
CURRENT: 3.0 A
FEATURES
◇ Plastic package has Underwriters Laborator 111 Flammability Classification 94V-0
◇ For surface mounted applications
◇ Low profile package
◇ Built-in strain relief
◇ Metal silicon junction, majority carrier conduction
◇ High surge capability
◇ High current capability,low forward voltage drop
◇ Low power loss,high effciency
◇ For use in low voltage high frequency inverters,free 111 wheeling and polarity protection applications
◇ Guardring for overvoltage protection
◇ High temperature soldering guaranteed:250o C/10 1 11 seconds at terminals
MECHANICAL DATA
◇ Case:JEDEC DO-214AA,molded plastic over 1111passivated chip
◇ Terminals:Solder Plated, solderable per MIL-STD-750, 1111Method 2026
◇ Polarity: Color band denotes cathode end
◇ Weight: 0.003 ounces, 0.093 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25℃ ambient temperature unless otherwise specified
| B320B | B330B | B340B | B350B | B360B | UNIT | ||
|---|---|---|---|---|---|---|---|
| Device marking code | B2B | B3B | B4B | B5B | B6B | ||
| Maximum recurrent peak reverse voltage | VRRM | 20 | 30 | 40 | 50 | 60 | V |
| Maximum RMS voltage | VRWS | 14 | 21 | 28 | 35 | 42 | V |
| Maximum DC blocking voltage | VDC | 20 | 30 | 40 | 50 | 60 | V |
| Maximum average forword rectified current at TL (SEEFIG.1) (NOTE2) | I(AV) | 3.0 | A | ||||
| Peak forward surge current 8.3ms single half sine-wave superimposed on rated load(JEDEC Method) | IFSM | 100.0 | A | ||||
| Maximum instantaneous forward voltage at 3.0A(NOTE.1) | VF | 0.50 | 0.70 | V | |||
|
Maximum DC reverse current @TA=25℃ at rated DC blockjing voltage(NOTE1) @TA=100℃ |
IR | 0.5 | mA | ||||
| 20 | |||||||
| Typical thermal resitance (NOTE2) |
RθJA RθJL |
50.0 10.0 |
℃/W | ||||
| Operating junction temperature range | TSTG | -65--- +150 | ℃ | ||||
| Storage temperature range | TJ | -65--- +150 | ℃ | ||||
NOTE:
1.Pulse test:300μS pulse width,1%duty cy cle B320B-B360B
2. P.C.B.mounted with 0.55"X0.55"(14.0X14.0mm2)copper pad areas
