NDT452AP Power Mosfet Transistor P Channel Enhancement Mode Field Effect Transistor

Good quality Programmable IC Chips for sales
Good quality Programmable IC Chips for sales
We have cooperate with Anterwell near 7 years. always very good quality good service. Original and very fast delivery. A very good partner.

—— Clemente From Brzail

I'm doing business with Anterwell from 2006, from small to big orders. Reliable!

—— Ingalill From Sweden

Sharon is a very good girl, we are very happy to cooperate with her. Competitive price and professional. Never have quality problem with them.

—— Alfredo From USA

We always buy XILINX parts from Anterwell. High quality with good price. Hope can have more business with you.

—— Mr Babak From Iran

I'm Online Chat Now

NDT452AP Power Mosfet Transistor P Channel Enhancement Mode Field Effect Transistor

China NDT452AP Power Mosfet Transistor P Channel Enhancement Mode Field Effect Transistor supplier

Large Image :  NDT452AP Power Mosfet Transistor P Channel Enhancement Mode Field Effect Transistor

Product Details:

Place of Origin: original factory
Brand Name: Anterwell
Certification: new & original
Model Number: NDT452AP

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: Negotiate
Packaging Details: Please contact me for details
Delivery Time: 1 day
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 9500pcs
Contact Now
Detailed Product Description
Drain-Source Voltage: -30 V Gate-Source Voltage: ±20 V
Drain Current - Continuous: -5 A Operating And Storage Temperature: -65 To 150 °C
High Light:

power mosfet ic

,

silicon power transistors



NDT452AP

P-Channel Enhancement Mode Field Effect Transistor



General Description

Power SOT P-Channel enhancement mode power field effect transistors are produced using Fairchild's proprietary, high cell density, DMOS technology. This very high density process is especially tailored to minimize on-state resistance and provide superior switching performance. These devices are particularly suited for low voltage applications such as notebook computer power management and DC motor control.



Features

• -5A, -30V. RDS(ON) = 0.065W @ VGS = -10V

                   RDS(ON) = 0.1W @ VGS = -4.5V.

• High density cell design for extremely low RDS(ON).

• High power and current handling capability in a widely used surface mount package.



NDT452AP Power Mosfet Transistor P Channel Enhancement Mode Field Effect Transistor



Absolute Maximum Ratings TA = 25°C unless otherwise noted

Symbol Parameter NDT452AP Units
VDSS Drain-Source Voltage -30 V
VGSS Gate-Source Voltage ±20 V
ID

Drain Current - Continuous         (Note 1a)

  - Pulsed

-5 A
-15
PD

Maximum Power Dissipation       (Note 1a)

                                                     (Note 1b)

                                                     (Note 1c)

3 W
1.3
1.1
TJ ,TSTG Operating and Storage Temperature Range -65 to 150 °C

Notes:

1. RθJA is the sum of the junction-to-case and case-to-ambient thermal resistance where the case thermal reference is defined as the solder mounting surface of the drain pins. RθJC is guaranteed by design while RqCA is determined by the user's board design.

NDT452AP Power Mosfet Transistor P Channel Enhancement Mode Field Effect Transistor

Typical RθJA using the board layouts shown below on 4.5"x5" FR-4 PCB in a still air environment:

    a. 42℃/W when mounted on a 1 in2 pad of 2oz copper.

    b. 95℃/W when mounted on a 0.066 in2 pad of 2oz copper.

    c. 110℃/W when mounted on a 0.0123 in2 pad of 2oz copper.

NDT452AP Power Mosfet Transistor P Channel Enhancement Mode Field Effect Transistor

Scale 1 : 1 on letter size paper
